Quick Facts
Printer Cost: $22,995.00
Monthly Use: 2,500-15,000+
Ink Type: Dye
Print Speed: Medium
Max Print Width: 11.7” (297mm)
Max Roll Diameter: 8 in (203 mm)
Wide-Format & Durable Overprinting System
A Durable Overprinting System Designed for Converters & Manufacturers
- High print speed up to 18 inches per second (27m/min or 90 ft per minute)
- Superior print resolution up to 1200 dpi
- Print width up to 11.7” (297mm)
- Automized calibration of print height (up to 100mm)
- Full-color printing (CMYK)
The T3-OPX system enables high-quality, full-color, and durable overprinting directly onto materials with ink-receptive surfaces such as cardboard, postcards, boxes, paper bags, wooden planks, or thicker objects like blister envelopes or folded boxes ready for shipment.
One-time setup
With the T3-OPX, it is easy to switch between substrates without making equipment adjustments. The pressure-sensitive entry plate takes 10 seconds to automatically adjust the print height, which is then stored in the media profiles for future use.
Durable Overprinting inks
The pigmented ink provides durability on a wide range of porous media and has tested great for lightfastness, water durability, and scratch resistance. The pigment inks adhere to porous media. They have received the BS5609 Section 3 certification, having survived five weeks of sloshing cold saltwater.
Versatile production runs
Designed for 24/7 production, the T3-OPX mounts on host systems with runs of up to 18 ips (90 feet per minute), automatically adjusting for variances in speed, timing, and spacing. Integrated aerosol fans and an optional material cleaner help to maintain stable, high-quality production.
Easy setup
The brilliant automized height calibration (up to 100mm) makes changing to a new type of material simple. With the press of a button, the T3-OPX seamlessly moves the material under the print unit and calibrates the height using the pressure-sensitive entry plate; all it requires is placing the material on the conveyor table.
ROI
The T3-OPX can deliver real ROI to businesses by quickly expanding products and services to attract new or current customers with private labeling for seasonal or promotional events. Versatile and easy-to-use, the T3-OPX is a perfect solution for label converters, print shops, manufacturers, contract packaging solutions, and secondary label logistics partners.
Printer | |
Print Method: | Enter Specs Here |
Inks: | Pigmented ink, 4 Individual CMYK cartridges |
Print Resolution: | 1200 x 1200 dpi |
Print Speed: | Up to 18 ips (27m/min) |
Print Width: | 11.7” (297mm) |
Media | |
Media Types: | Uncoated Paper, Card board, paper board |
Media Width: | Depends on transport/installation, 600mm (Trojan standard table), 1000mm (Trojan wide table) |
Media Length: | 35.5” |
Thickness: | 0 – 100mm (automatic height calibration) |
Maximum Roll Diameter: | Enter Specs Here |
Core Diameter: | Enter Specs Here |
Media Sensors: | Enter Specs Here |
Die-Cut Label Gap: | Enter Specs Here |
Black mark: | Enter Specs Here |
General | |
Cutter/sheeter: | Enter Specs Here |
Interfaces: | 802.3 LAN (10/100/1000) Ethernet port |
Operating System: | TrojanControl Software RIP |
Barcode Font: | Enter Specs Here |
2-D Code Printing: | Enter Specs Here |
Operating Temperature: | 15° to 30° C (59° to 86° F) |
Storage Temperature: | –40° to 60° C (–40° to 140° F) |
Overall Dimensions: | |
Weight: | Print unit weight: 20 kg; Media cleaning unit weight: 3.5 kg |
Rated Voltage: | TBD |
Rated Frequency: | TBD |
Warranty: | 12 Month Manufacturer’s Parts & Labor Warranty (excludes wear parts and supplies) |
