Wide-Format & Durable Overprinting System
A Durable Overprinting System Designed for Converters & Manufacturers
- High print speed up to 18 inches per second (27m/min or 90 ft per minute)
- Superior print resolution up to 1200 dpi
- Print width up to 11.7” (297mm)
- Automized calibration of print height (up to 100mm)
- Full-color printing (CMYK)
The T3-OPX system enables high-quality, full-color, and durable overprinting directly onto materials with ink-receptive surfaces such as cardboard, postcards, boxes, paper bags, wooden planks, or thicker objects like blister envelopes or folded boxes ready for shipment.
With the T3-OPX, it is easy to switch between substrates without making equipment adjustments. The pressure-sensitive entry plate takes 10 seconds to automatically adjust the print height, which is then stored in the media profiles for future use.
Durable Overprinting inks
The pigmented ink provides durability on a wide range of porous media and has tested great for lightfastness, water durability, and scratch resistance. The pigment inks adhere to porous media. They have received the BS5609 Section 3 certification, having survived five weeks of sloshing cold saltwater.
Versatile production runs
Designed for 24/7 production, the T3-OPX mounts on host systems with runs of up to 18 ips (90 feet per minute), automatically adjusting for variances in speed, timing, and spacing. Integrated aerosol fans and an optional material cleaner help to maintain stable, high-quality production.
The brilliant automized height calibration (up to 100mm) makes changing to a new type of material simple. With the press of a button, the T3-OPX seamlessly moves the material under the print unit and calibrates the height using the pressure-sensitive entry plate; all it requires is placing the material on the conveyor table.
The T3-OPX can deliver real ROI to businesses by quickly expanding products and services to attract new or current customers with private labeling for seasonal or promotional events. Versatile and easy-to-use, the T3-OPX is a perfect solution for label converters, print shops, manufacturers, contract packaging solutions, and secondary label logistics partners.
|Inks:||Pigmented ink, 4 Individual CMYK cartridges|
|Print Resolution:||1200 x 1200 dpi|
|Print Speed:||Up to 18 ips (27m/min)|
|Print Width:||11.7” (297mm)|
|Media Types:||Uncoated Paper, Card board, paper board|
|Media Width:||Depends on transport/installation, 600mm (Trojan standard table), 1000mm (Trojan wide table)|
|Thickness:||0 – 100mm (automatic height calibration)|
|Maximum Roll Diameter:|
|Die-Cut Label Gap:|
|Interfaces:||802.3 LAN (10/100/1000) Ethernet port|
|Operating System:||TrojanControl Software RIP|
|2-D Code Printing:|
|Operating Temperature:||15° to 30° C (59° to 86° F)|
|Storage Temperature:||–40° to 60° C (–40° to 140° F)|
|Weight:||Print unit weight: 20 kg; Media cleaning unit weight: 3.5 kg|
|Warranty:||12 Month Manufacturer’s Parts & Labor Warranty (excludes wear parts and supplies)|
